| Features
Easy operation and Comfort
- Fully hydrostatic drive with a forward-reverse lever on each side of the dashboard.
- Two variable speeds allow the selection of the optimum working speed as well as faster transit speeds.
- Auto and manual vibration modes are selected via a switch on the dashboard.
- Vibration on/off switches are also located on each of the forward-reverse lever grips.
- High curb clearance and small side overhang enable the roller to work right up to curbs and walls.
- Pressurized and fully corrosion-proof water sprinkler system includes polyethylene tank, stainless pipes and quick-mount type brass spray nozzles along with a triple filtering system.
Ergonomically designed operator seat
- The soft, seamless bench seat has rounded coners offering the best riding comfort while protecting itself from rain or water penetration.
- With the wide bench seat and forward-reverse levers on both sides, the operator can take up the optimum driving position.
Thus, compaction on shoulders and pavement joints is facilitated due to the easy-to-observe drum edges.
High safety standards
- Excellent all-round visibility.
- In addition to the hydraulic service brake and S.A.H.R.
(spring applied, hydraulically released type) secondary brake, a pedal brake is provided for emergency stops.
Excellent seviceability
- The engine hood opens fully for easy access to areas requiring daily maintenance; engine, hydraulic system, fuel system, battery, etc.
- Quick-mount water spray nozzles can be mounted or dismounted without tools.
They are made of brass, therefore, durability is unsurpassed.
Standard equipment
- The engine complies with new emission standards.
- Standard equipment includes head lights, rear working lights, turning signals, spring-loaded plastic scrapers (outer and inner),
mirrors, instruments and gauges.
|
